Product Description of Spektrum O-SPMX54S100H5 Smart G2 LiPo battery 4S 5000mAh 100C with IC5 connector and microchip
The Spektrum O-SPMX54S100H5 Smart G2 LiPo battery 4S 5000mAh 100C with IC5 connector and microchip is a high-performance, data-rich power solution designed for RC surface vehicles that demand maximum burst output and intelligent battery management. With a 14.8V 4-cell configuration and a 100C continuous discharge rating, this hardcase LiPo delivers explosive acceleration and sustained power for competitive RC cars and boats. Built on Spektrum’s advanced Smart G2 platform, the battery features balance-free charging, automatic storage discharge, and integrated memory—all accessible through a single IC5 connection. Whether you're racing or bashing, this battery offers the durability, speed, and intelligence to elevate your setup.
Key features of the Spektrum O-SPMX54S100H5 Smart G2 LiPo battery
- 100C continuous discharge – delivers high burst power for demanding surface applications
- Smart G2 technology – enables balance-free charging and automatic data sync
- Auto storage discharge – maintains battery health during idle periods
- Integrated microchip – logs charge cycles, temperature, and error events
- Hardcase with metal side plates – improves durability and heat dissipation
- IC5 connector with EC5 compatibility – ensures secure connection and Smart data transfer
- Balance-free charging – simplifies setup with single-wire IC5 interface
- 10 AWG wire – supports high current flow with minimal resistance
- 55.5Wh output – provides sustained energy for extended runs
- 520g weight – balances performance and chassis load
Why is the Spektrum O-SPMX54S100H5 battery ideal for RC cars and boats?
The Spektrum surface battery with IC5/EC5 compatibility and Smart auto storage mode is engineered for high-performance surface platforms. Its 100C discharge rating supports rapid acceleration and high-speed operation, making it ideal for competitive racing and power-hungry setups. The 5000mAh capacity ensures long run times, while the hardcase construction protects against impact and vibration. With EC5 compatibility, the IC5 connector integrates seamlessly into existing systems, offering both physical robustness and Smart data communication. This combination of power, protection, and intelligence makes the battery a top-tier choice for serious RC drivers.
How does Smart G2 technology simplify charging and battery management?
The Spektrum O-SPMX54S100H5 14.8V Smart G2 hardcase battery with auto discharge and metal side plates features next-generation Smart G2 technology that eliminates the need for a separate balance lead. All balancing and health data are transmitted through the IC5 connector’s data wire, allowing users to charge and balance with a single plug. When connected to a Spektrum Smart charger, the battery automatically uploads its parameters—voltage, capacity, charge rate, and health status—streamlining the charging process and reducing setup time. The integrated microchip also stores historical data, helping users track performance and identify potential issues before they affect reliability.
What makes balance-free charging a game-changer?
The Spektrum O-SPMX54S100H5 4-cell LiPo with 10 AWG wire and balance-free IC5 charging introduces a simplified charging experience that eliminates the need for separate balance connectors. This innovation reduces cable clutter, speeds up setup, and minimizes wear on connectors. All cell balancing is handled internally and communicated through the IC5 data wire, ensuring accurate voltage alignment without manual intervention. For users who value convenience and reliability, this feature transforms how batteries are maintained and charged—especially in fast-paced environments where downtime must be minimized.
How does the hardcase design enhance durability and thermal performance?
The Smart G2 LiPo battery with integrated memory and 100C continuous discharge is housed in a rugged hardcase with internal metal side plates. These plates serve a dual purpose: they protect the cells from punctures and physical damage during crashes or rough landings, and they help dissipate heat generated during high-current discharge. This thermal management is critical for maintaining consistent performance and preventing overheating, especially in vehicles that operate under extreme conditions. The hardcase also ensures structural integrity, making the battery suitable for off-road, on-road, and marine applications.
What kind of data does the integrated microchip record?
The Spektrum O-SPMX54S100H5 with 5C max charge rate, 55.5Wh output, and 520g weight includes a microchip that stores a comprehensive set of performance metrics. These include battery brand, chemistry, cell count, capacity, C rating, temperature, and charge/discharge cycles. Additionally, the chip logs error events such as overcharge, over-discharge, and overheating. This data is automatically uploaded to a Spektrum Smart charger upon connection, allowing users to monitor battery health and adjust settings as needed. The ability to track historical performance helps extend battery life and ensures safe operation across all use cases.
Is this the best 4S LiPo for high burst power and Smart data logging?
For drivers seeking maximum punch, intelligent control, and rugged reliability, the Smart hardcase LiPo with 14.8V output, 5000mAh capacity, and 100C discharge rating delivers on all fronts. Its Smart G2 platform offers balance-free charging, automatic storage discharge, and advanced data logging—all through a single IC5 connection. The hardcase design and metal side plates ensure durability, while the 100C discharge rating provides the power needed for aggressive driving and high-speed performance. Whether you're upgrading your RC car or outfitting a high-powered boat, this battery offers the features and resilience needed to dominate the track or water.
Why should you buy the Spektrum O-SPMX54S100H5 Smart G2 battery?
The Spektrum O-SPMX54S100H5 Smart G2 LiPo battery 4S 5000mAh 100C with IC5 connector and microchip is a complete solution for surface RC enthusiasts who demand performance, safety, and simplicity. With its 14.8V output, 5C charge rate, and balance-free charging, this battery streamlines your workflow while delivering the power needed for competitive setups. The Smart G2 technology ensures that every charge is optimized, every discharge is logged, and every run is backed by intelligent data. Buy Spektrum O-SPMX54S100H5 Smart G2 battery for RC cars and boats needing high burst power.
Technical Specifications of Spektrum O-SPMX54S100H5 Smart G2 LiPo battery 4S 5000mAh 100C with IC5 connector and microchip
Brand, Model and Product Type
- Brand: Spektrum
- Model: O-SPMX54S100H5
- Product Type: Spektrum O-SPMX54S100H5 Smart G2 LiPo battery 4S 5000mAh 100C with IC5 connector and microchip, Spektrum O-SPMX54S100H5 14.8V Smart G2 hardcase battery with auto discharge and metal side plates, Spektrum O-SPMX54S100H5 4-cell LiPo with 10 AWG wire and balance-free IC5 charging, Spektrum O-SPMX54S100H5 with 5C max charge rate, 55.5Wh output, and 520g weight, Smart G2 LiPo battery with integrated memory and 100C continuous discharge, Spektrum surface battery with IC5/EC5 compatibility and Smart auto storage mode
Dimensions
- Product Length: 13.8 cm – compact footprint for surface vehicle battery trays
- Product Width: 4.6 cm – fits snugly in standard RC car and boat compartments
- Product Height: 3.5 cm – low-profile hardcase for secure mounting and heat control
- Product Weight: 520 g – balances power density with manageable chassis load
Battery Configuration and Electrical Specifications
- Battery Type: LiPo – lithium polymer chemistry for high energy density and discharge capability
- Battery Voltage: 14.8V – 4S configuration (3.7V per cell) for consistent surface power delivery
- Capacity: 5000mAh – suitable for extended run times and high-performance setups
- Discharge Rate: 100C continuous – supports aggressive throttle and sustained output
- Maximum Burst Discharge Rate: 100C – delivers peak current for acceleration and torque
- Maximum Charge Rate: 5C – allows fast charging when supported by Smart charger
- Maximum Charge Current: 5A – compatible with high-output charging systems
- Standard Charge Rate: 1C – recommended for routine charging cycles
- Watt Hours: 55.5Wh – provides reliable energy output for extended surface use
- Auto Storage: Yes – automatically discharges to 3.90V per cell after 72 hours of inactivity
Smart Technology and Data Features
- Smart Technology: G2 – enables balance-free charging and automatic data sync
- Integrated Microchip: Yes – stores battery brand, chemistry, cell count, capacity, C rating, temperature, and cycle history
- Error Logging: Yes – tracks overcharge, over-discharge, and overheating events for diagnostics and safety
- Smart Memory: Yes – remembers last charge settings for streamlined operation
- Customizable Charge Parameters: Yes – allows user-defined charge rates and auto storage settings
Connectors and Wiring
- Connector Type: IC5 – compatible with EC5 systems and supports Smart data transfer
- Balance Connector: Balance-free via IC5 – no separate balance lead required
- Wire Gauge: 10 AWG – supports high current flow with minimal resistance
Construction and Durability
- Case Type: Hardcase – protects cells from impact and puncture during surface use
- Internal Metal Side Plates: Yes – improves heat dissipation and structural integrity
Product Application
- Application: Surface – optimized for RC cars and boats requiring high burst power
- ROAR Approved: No – not certified for ROAR-sanctioned racing events
What’s in the Box
- 1 × Spektrum Smart G2 LiPo Battery 5000mAh 4S 100C with IC5 Connector
What You Require / What You Will Need
- Spektrum Smart Charger (required for full Smart G2 functionality)
- RC surface vehicle compatible with 4S 14.8V LiPo configuration
Sold Separately
- Spektrum Smart Charger with IC5 compatibility
- Battery straps or mounting accessories
