Manufacturer: Tamiya
Part Number: 58693
EAN: 4950344586936
Vehicle: On-Road

The Tamiya TA08 Pro chassis kit brings race-bred TRF420 technology into a versatile, highly tunable 1/10 touring platform. Its carbon fiber reinforced plastic stepped-V lower deck lowers the center of gravity and maximises torsional rigidity, translating into crisp turn-ins and rock-steady high-speed stability for club racers and hobbyists alike. Balanced electronics layout positions the battery pack on the right side at a 10° angle while mounting the servo, receiver and ESC on the left, ensuring consistent weight distribution through every corner. With a forward-placed spur gear ahead of the motor, steering feedback remains linear and predictable, whether you’re pushing lap records or fine-tuning a custom show build.

Key features of the Tamiya TA08 Pro chassis kit

• Stepped-V carbon fiber deck – sharpens corner entry and resists flex under load
• Dual belt drive – delivers smooth, backlash-free power transfer to both axles
• Oil-filled gear differentials – maintain consistent traction on varied surfaces
• Laid-down dampers – lower vehicle mass for crisper response and adjustability
• Floating servo mount – simplifies electronics installation and enhances balance
• Rotatable body mounts – switch between standard and 2 mm advanced ride-height

How does the Tamiya TA08 Pro chassis kit enhance on-track agility?

The combination of a stepped-V lower deck and low-profile geometry in the Tamiya TA08 Pro chassis kit slashes chassis roll, so lap-time killing understeer becomes a thing of the past. By physically separating the motor, spur gear, and battery pack, this chassis achieves ideal weight bias—enabling faster directional changes and a more responsive throttle to steering transition. Hobbyists will appreciate how minimal flex improves tyre contact under high-G loads, making mid-corner adjustments feel both accurate and confidence-inspiring.

What gives the Tamiya 1/10 TA08 Pro 4WD chassis its balanced weight distribution?

Positioning the pack on the right and packing electronics on the left of the Tamiya 1/10 TA08 Pro 4WD chassis lowers the polar moment of inertia, letting drivers flick between apexes with negligible yaw resistance. This side-by-side separation prevents weight shift from magnifying under acceleration or braking, resulting in a consistently neutral handling platform. Whether you’re tackling sweeping corners or tight chicanes, the chassis maintains its composure and traction balance.

Design inspired by TRF420 racing lineage

The chassis architecture in this Tamiya belt-driven 4WD RC kit owes its DNA to the TRF420 world-championship contender. From the precision aluminium motor mount to the high-torque servo saver, every component reflects years of competition data. Builders will recognize the front-mounted spur gear configuration and the carbon-reinforced lower deck as key elements that transform a standard touring car into a lap-time-hunting machine.

Can the Tamiya belt-driven 4WD RC kit handle rigorous racing conditions?

With full ball bearings, steel front and aluminium rear universal shafts, plus front and rear oil-filled gear differentials, this kit thrives under the demands of competitive running. The Tamiya Super Short Big Bore dampers keep the center of gravity low, maintaining tyre contact over bumps and undulations. Drivers pushing for podium finishes will find this kit among the best Tamiya 1/10 touring car for racing options, thanks to its durability and tunability.

Why choose the Tamiya TAM58693 touring chassis for your build?

Whether you’re on a budget or building a show-car masterpiece, the Tamiya TAM58693 touring chassis balances cost and performance—making it an affordable Tamiya 4WD chassis for custom builds. Its modular layout accommodates a wide variety of brushless motors, electronics packs, and body shells. Plus, adjustable camber, caster and ride-height settings give you full control over handling characteristics without breaking the bank.

Conclusion & Next Steps

From club-level practice sessions to friendly drag challenges in the backyard, the Tamiya TA08 Pro chassis kit delivers professional-grade performance and unparalleled tuning potential. When you’re ready to push your setup to its limits, buy Tamiya TA08 Pro chassis kit today.

Technical speciications of the Tamiya TAM58693

Brand, Model & Product Type

• Brand: Tamiya
• Model: TAM58693
• Product Type: Tamiya TA08 Pro chassis kit, Tamiya TAM58693 touring chassis, Tamiya 1/10 TA08 Pro 4WD chassis, Tamiya Super Short Big Bore dampers, Tamiya stepped-V touring chassis

Dimensions & Weight

• Dimensions: Length 37.3 cm, Width 18.7 cm, Wheelbase 25.7 cm

Chassis & Drivetrain

• Tamiya TA08 Pro chassis kit uses a carbon fiber reinforced plastic stepped-V lower deck for maximum rigidity
• Tamiya 1/10 TA08 Pro 4WD chassis features a forward-mounted spur gear ahead of the motor for linear steering response
• Tamiya belt-driven 4WD RC kit employs dual belts to power front and rear oil-filled gear differentials
• Aluminium motor mount ensures secure, consistent motor positioning under load
• Full ball bearings throughout the drivetrain reduce friction and improve efficiency

Suspension & Damping

• 4-wheel independent double wishbone suspension with A-design upper arms for precise wheel control
• Tamiya Super Short Big Bore dampers laid down to lower center of gravity and offer adjustable damping rates
• Camber and caster angles adjustable via aluminium turnbuckle shafts and lower arm spacers

Steering & Electronics Mount

• 3-piece carbon fiber steering tie-rod for fine Ackermann and steering geometry tuning
• Floating servo mount simplifies electronics installation and preserves chassis balance
• Hi-torque servo saver protects steering linkage components from impact damage

Drive Shafts & Bearings

• Front universal shafts in steel; rear shafts in aluminium – balances strength and reduced rotating mass
• Full ball bearings throughout lower deck and suspension pivots — minimises wear and maximises speed

Adjustability & Customisation

• Rotatable body mounts allow standard or 2 mm advanced ride-height positions
• Optimised battery, servo, receiver and ESC layout for modular servo and battery choices

Required Separately

• 190 mm touring car body shell
• Type 540 motor (brushless recommended), ESC, low-profile servo
• Tires
• 2-channel R/C system
• 7.2–7.4 V battery pack & charger

Warranty

• 1 year manufacturer’s warranty
