Castle Creations CC BEC 2.0 15A Waterproof Voltage Regulator P-CC010-0153-00

• Brand: Castle Creations
• Model Number: P-CC010-0153-00
• Product Type: Waterproof Voltage Regulator / Battery Eliminator Circuit (BEC)
• Maximum Peak Power: 15 amps
• Maximum Input Voltage: 14S LiPo (58.8V) without brake enabled, or 12S LiPo (50.4V) with brake enabled
• Maximum Surface Operating Voltage: 12S (50.4V)
• Adjustable Output Voltage Range: 4.75V to 12V (configurable via Castle Link2)
• Default Output Voltage: 5.25V
• Output Current at 4.75-6.0V: 10 amps
• Output Current at 6.25-8.5V: 9 amps
• Output Current at 8.75-10.0V: 8 amps
• Output Current at 10.25-12.0V: 7 amps
• Length: 35mm
• Width: 18mm
• Height: 19mm
• Weight: 28 grams
• Case Material: CNC machined aluminium
• Waterproof Rating: Waterproof sealed enclosure
• Output Wiring: Heavy-duty dual output wires
• Programming: Castle Link2 compatible (sold separately)
• Suitable Applications: Surface RC (cars, crawlers, trucks), racing, splashing environments

Overview

The Castle Creations CC BEC 2.0 Waterproof is a professional-grade external voltage regulator designed specifically for demanding RC applications where clean, reliable power is essential. Built on Castle's proven and trusted BEC platform that has earned the confidence of hundreds of thousands of hobbyists worldwide, this next-generation voltage regulator delivers consistent performance to sensitive radio equipment, modern high-demand digital servos, and onboard camera systems. Whether you're running a competitive RC car in the UK or powering a crawler setup that demands waterproof electronics, the CC BEC 2.0 Waterproof offers the protection and performance your expensive hobby equipment deserves.

Designed and assembled in the USA, the CC BEC 2.0 Waterproof combines cutting-edge engineering with practical features that address the real-world needs of racers, crawlers, and serious RC enthusiasts. The waterproof variant features a CNC machined aluminium case that provides exceptional durability and weather resistance, making it ideal for splashing, muddy terrain, and challenging outdoor conditions. At just 28 grams and measuring only 35mm in length, this compact regulator integrates seamlessly into tight spaces whilst delivering a robust 15 amp peak power capacity—enough to safely power today's power-hungry digital servos, accessory systems, and advanced electronics. If you're serious about protecting your investment in high-end RC equipment, the CC BEC 2.0 Waterproof is the professional choice.

This voltage regulator complements Castle's established line of BECs with enhanced voltage handling capabilities that set it apart from previous generations. The CC BEC 2.0 can handle impressive input voltage ranges—up to 14S LiPo without brake enabled, or 12S with brake functionality activated. This flexibility makes it suitable for everything from standard racing setups to high-voltage powered platforms. Heavy-duty dual output wires ensure clean power delivery to your sensitive radio equipment, whilst the adjustable output voltage (configurable from 4.75 to 12 volts using Castle Link2 programming, sold separately) means you can fine-tune power delivery to match your specific servo and accessory requirements.

Key Features

• 15 Amp Peak Power Rating — The waterproof variant delivers 15 amps of continuous power capacity, providing sufficient current for multiple high-torque digital servos and modern onboard accessories without voltage sag or performance loss during demanding manoeuvres.
• Waterproof CNC Machined Aluminium Case — The rugged, precision-engineered aluminium housing is sealed against water ingress and built to withstand the punishment of serious RC use, including splashing, mud, and wet conditions that would compromise lesser regulators.
• Adjustable Output Voltage 4.75V to 12V — Castle Link2 software allows you to customise the output voltage across a wide range (default 5.25V), enabling you to match power delivery precisely to your servo specifications and accessory requirements without hardware modifications.
• Heavy-Duty Dual Output Wires — Premium quality output connectors and wiring deliver clean, noise-free power to your receiver and servo channels, protecting sensitive digital electronics from electrical interference and voltage spikes that can cause unpredictable behaviour.
• Extreme Voltage Handling Capability — Supporting up to 14S LiPo input without brake or 12S with brake enabled, this regulator future-proofs your setup for high-voltage battery systems, offering flexibility that most mid-range regulators simply cannot match.
• Compact, Lightweight Design — Weighing just 28 grams with dimensions of only 35 x 18 x 19mm, the CC BEC 2.0 Waterproof fits easily into tight spaces where conventional battery eliminators would not, making it perfect for space-constrained RC chassis designs.
• Proven Castle Platform Heritage — Built upon the established BEC technology that has powered hundreds of thousands of RC vehicles globally, this regulator carries the reputation and reliability you can trust for critical power management tasks.
• Scalable Current Output Ratings — Output current adjusts intelligently based on voltage setting (10A at 4.75-6.0V, 9A at 6.25-8.5V, 8A at 8.75-10.0V, and 7A at 10.25-12.0V), ensuring optimal performance across your entire operating range.

Technical Performance

The Castle Creations CC BEC 2.0 Waterproof represents genuine engineering advancement in voltage regulation technology for serious RC hobbyists. The CNC machined aluminium case is not merely cosmetic—it provides superior heat dissipation compared to plastic alternatives, allowing the regulator to maintain stable output voltage even under sustained high-current draw from multiple servos and accessories. This thermal management capability is critical when running modern digital servos that demand consistent voltage for smooth, predictable operation. The heavy-duty dual output wires feature heavy gauge construction that minimises voltage drop and resistance losses, ensuring that every volt produced by the regulator actually reaches your receiver and servos without attenuation. The regulator's ability to handle input voltages spanning from 2S all the way to 14S LiPo cells (58.8V maximum without brake) demonstrates engineering prowess that rivals commercial-grade power management equipment, yet the compact 35mm length and 28-gram weight ensure it integrates into even the most space-constrained RC platforms. The adjustable output voltage system, controlled via Castle Link2 software, provides precision output control in discrete steps, allowing you to optimise power delivery for your specific servo characteristics and avoiding the one-size-fits-all compromises of fixed-output regulators. Whether you're running a 5V receiver system with 6V digital servos or managing a complex multi-channel accessory setup requiring 10V or higher, the CC BEC 2.0 Waterproof adapts to your requirements.

What's in the Box

• Castle Creations CC BEC 2.0 Waterproof voltage regulator unit
• Heavy-duty dual output wires for servo and receiver connection

What You Need to Complete

• Castle Link2 programming cable (sold separately) — required to adjust output voltage settings beyond the default 5.25V configuration
• LiPo battery compatible with your RC platform (2S to 14S supported)
• RC receiver and digital servo system

Frequently Asked Questions

• What is the maximum input voltage this BEC can handle? — The CC BEC 2.0 Waterproof supports up to 14S LiPo (58.8V) without brake enabled, or 12S (50.4V) when brake functionality is activated. This extreme voltage capability makes it suitable for high-powered RC platforms and future-proofs your equipment investment against voltage creep as battery technology evolves.
• Can I adjust the output voltage, and if so, how? — Yes, the output voltage is fully adjustable from 4.75V to 12V using Castle Link2 software (sold separately). The default factory setting is 5.25V, but you can customise this to match your specific servo and receiver requirements with precision adjustment capability.
• What is the difference between the standard CC BEC 2.0 and this waterproof version? — The CC BEC 2.0 Waterproof features a CNC machined aluminium case with waterproof sealing, rated for 15 amps peak power, and is specifically designed for demanding surface applications including crawlers, racers, and splashing scenarios. The standard CC BEC 2.0 is a lighter 0.7 ounce design rated for 14 amps peak, optimised for sport flying, helicopters, and UAVs. Both share the same voltage adjustment capability and extreme input voltage handling.
• How much current can this regulator deliver at different voltage settings? — Current output is scalable based on your chosen voltage: 10 amps at 4.75-6.0V output, 9 amps at 6.25-8.5V, 8 amps at 8.75-10.0V, and 7 amps at 10.25-12.0V. This intelligent current management prevents overload whilst optimising performance across your entire operating voltage range.
• Is this suitable for RC cars and trucks in the UK market? — Absolutely. The CC BEC 2.0 Waterproof is purpose-built for demanding RC car applications, particularly crawlers, racers, and vehicles that encounter wet or muddy conditions. The waterproof aluminium housing and 15-amp capacity make it ideal for competitive RC racing setups and adventure-focused RC platforms throughout the UK.
• What batteries work with this voltage regulator? — This regulator works with 2S through 14S LiPo batteries (or equivalent cell-count battery chemistry). You can also use traditional NiMH packs within the compatible voltage range. The input voltage range of up to 58.8V without brake provides flexibility across virtually all hobby-grade RC battery systems.
• Do I need Castle Link2 to use this regulator? — No, the regulator functions immediately out of the box with a factory default output voltage of 5.25V, which suits most standard receiver and servo combinations. However, Castle Link2 (sold separately) is highly recommended if you want to customise the output voltage to optimise performance for your specific equipment.
• Can I use multiple BEC units together on the same RC vehicle? — No. Castle explicitly states that the CC BEC 2.0 should never be operated in series or parallel with another BEC or backup receiver pack connected to the RX/Servo side of the circuit. Using multiple BECs creates conflicting voltage outputs that can damage sensitive electronics.
