Spektrum Firma 80A Brushless Sensored Smart ESC, Outrunner Overview
Feature-packed FirmaT Smart ESCs deliver power and intelligence all-in-one, with no additional modules or links required. The SpektrumT Firma Smart 80 Sensored/Sensorless Brushless ESC: Outrunner is a great choice for 1/10th scale crawlers and scalers running on 2S - 4S LiPo power. This Smart ESC includes the ability to infinitely adjust drag brake on the fly from compatible Spektrum transmitters. This waterproof* 80A Sensored/Sensorless Outrunner ESC drives your 1/10th scale crawler or scaler through almost any conditions imaginable, with ultra-smooth control, performance, and reliability - while feeding real-time telemetry straight to your SpektrumT transmitter!
The Spektrum P-SPMXSE2060S Firma 80A Smart ESC with 2S–4S LiPo support, IC3 input, and 480A burst current is a compact, high-performance electronic speed control system designed for 1/10 scale crawlers and scalers. Engineered with both sensored and sensorless brushless motor compatibility, this ESC delivers ultra-smooth throttle response, real-time telemetry, and rugged waterproof protection. Whether you're navigating technical terrain or trail running through unpredictable conditions, the Spektrum P-SPMXSE2060S offers precision control and reliability in a lightweight, space-efficient form factor.
Key features of the Spektrum P-SPMXSE2060S Firma 80A Smart ESC
- Smart telemetry – real-time data transmission including RPM, voltage, temperature, and battery capacity
- Infinitely adjustable drag brake – on-the-fly tuning from compatible Spektrum transmitters
- Multiple programming options – button interface, Smart ESC Programming Box, and SmartLink USB app
- Waterproof housing – all-weather protection for trail rigs and scalers
- Failsafe logic and multi-point protection – includes over-current, thermal, and low-voltage safeguards
- 6A BEC – stable power delivery with selectable 6V or 7.4V output
- Compact form factor – 48mm length and 108g weight for tight installs
Why is the Spektrum P-SPMXSE2060S ideal for 1/10 scale crawlers?
The Spektrum P-SPMXSE2060S brushless ESC for 1/10 scale scalers with infinitely adjustable drag brake is purpose-built for low-speed precision and terrain adaptability. With a continuous current rating of 80A and a burst capacity of 480A, this ESC delivers consistent torque and control across varied surfaces. Its drag brake can be fine-tuned directly from compatible Spektrum transmitters, allowing drivers to adjust braking force based on incline, weight, and terrain type. Whether you're rock crawling or trail cruising, the Spektrum P-SPMXSE2060S ensures your vehicle remains stable and responsive.
How does Smart telemetry enhance trail performance?
The Smart ESC for crawlers and trail rigs with one-wire telemetry, failsafe logic, and waterproof housing offers seamless telemetry integration without the need for additional sensors or modules. Through a single wire, the ESC transmits RPM, temperature, battery voltage, and capacity directly to your Spektrum transmitter. This real-time feedback allows drivers to monitor system health, optimize performance, and make informed adjustments during runs. When paired with a Spektrum Smart LiPo battery, the ESC also provides detailed battery diagnostics such as cycle count, cell voltage, and remaining capacity.
What programming options are available for the Spektrum P-SPMXSE2060S?
The Spektrum digital ESC with 3.5mm motor leads, 80A continuous output, and SmartLink programming options supports multiple programming pathways to suit different user preferences. For quick adjustments, the onboard button interface allows basic configuration without external tools. For advanced tuning, users can connect the Smart ESC Programming Box or use the SmartLink USB app to access a full suite of settings. These options enable customization of throttle curves, drag brake strength, cutoff thresholds, and more—ensuring the ESC can be tailored to match your driving style and terrain conditions.
Can the Spektrum P-SPMXSE2060S handle wet and rugged environments?
Absolutely. The Spektrum P-SPMXSE2060S waterproof crawler ESC with Smart telemetry, 3.5mm motor bullets, and 6A BEC is built for all-weather operation. Its waterproof housing protects internal components from moisture, dust, and debris, making it suitable for use in rain, snow, and mud. The rugged construction and compact dimensions allow for flexible placement within tight chassis layouts, while the high heat-resistant IC3 connector ensures reliable power delivery. Whether you're navigating unpredictable terrain or pushing your vehicle to its limits, this ESC is engineered to perform under pressure.
What protection systems are built into the Spektrum P-SPMXSE2060S?
The high-performance surface ESC with ARM M4 processor, sensorless/sensored support, and multi-point protection includes a comprehensive set of safety features. Over-current protection prevents damage during electrical surges, while thermal protection safeguards against overheating. The programmable low-voltage cutoff protects your LiPo battery from over-discharge, and failsafe logic ensures controlled shutdown in the event of signal loss. These systems work together to maintain the integrity of your electronics and provide peace of mind during high-stress driving scenarios.
Is the Spektrum P-SPMXSE2060S easy to install and integrate?
Installation is straightforward thanks to the ready-to-use design of the Spektrum P-SPMXSE2060S with 6V/7.4V BEC output, 108g weight, and 48mm length for compact installs. No soldering is required, and the ESC comes equipped with IC3 connectors that are compatible with Spektrum Smart LiPo batteries. The 3.5mm motor bullet connectors provide secure and efficient power delivery to brushless motors, while the compact footprint allows for flexible placement in 1/10 scale chassis. With plug-and-play simplicity and full compatibility with Spektrum Smart receivers and transmitters, integration into your existing setup is seamless.
Buy Spektrum P-SPMXSE2060S Firma 80A Smart ESC for 1/10 scale crawlers and scalers with Smart telemetry.
Brand, Model and Product Type
- Brand: Spektrum
- Model: P-SPMXSE2060S
- Product Type: Spektrum P-SPMXSE2060S Firma 80A Smart ESC with 2S–4S LiPo support, IC3 input, and 480A burst current, Spektrum P-SPMXSE2060S waterproof crawler ESC with Smart telemetry, 3.5mm motor bullets, and 6A BEC, Spektrum P-SPMXSE2060S brushless ESC for 1/10 scale scalers with infinitely adjustable drag brake, Spektrum P-SPMXSE2060S with 6V/7.4V BEC output, 108g weight, and 48mm length for compact installs, Smart ESC for crawlers and trail rigs with one-wire telemetry, failsafe logic, and waterproof housing, High-performance surface ESC with ARM M4 processor, sensorless/sensored support, and multi-point protection
Dimensions
- Length: 4.8 cm – compact enough for tight 1/10 scale chassis layouts
- Width: 5.8 cm – standard footprint for secure mounting and airflow
- Height: 3.8 cm – low-profile design for vertical clearance in trail rigs
- Weight: 108 g – lightweight for balanced crawler setups
Electrical and Performance Specifications
- ESC Type: Brushless – supports both sensored and sensorless motor configurations
- Application: Surface – optimized for 1/10 scale crawlers and scalers
- Input Voltage: 2S–4S LiPo – supports up to 14.8V for versatile power setups
- Maximum Continuous Current: 80A – delivers consistent torque for trail and crawl performance
- Maximum Burst Current: 480A – handles peak loads during throttle spikes and steep climbs
Connector and Output Configuration
- Battery Connector: IC3 – high heat-resistant input compatible with Spektrum Smart LiPo batteries
- Motor Output Lead: 3.5mm bullet connectors – secure and efficient connection for brushless motors
Processor and Control Features
- Processor: 32-bit ARM M4 – enables high-resolution signal input and precise motor output
- Programmable: Yes – supports multiple programming methods for flexible configuration
- Programming Options: Button interface, Smart ESC Programming Box, SmartLink USB App
- Forward/Reverse: Yes – includes full directional control for trail maneuverability
- Brakes: Infinitely adjustable drag brake – tunable directly from compatible Spektrum transmitters
Telemetry and Smart Technology
- Telemetry: Smart all-in-one – transmits RPM, voltage, temperature, and battery data via one-wire link
- Smart Battery Data: Compatible with Spektrum Smart LiPo – displays cycles, capacity, and cell voltage in real time
Protection and Safety Features
- Waterproof Rating: Yes – sealed housing for all-weather operation (refer to manual for details)
- Failsafe Protection: Yes – maintains control during signal loss or system fault
- Thermal Protection: Yes – prevents overheating during extended use
- Overload Protection: Yes – safeguards against electrical surges
- Low-Voltage Cutoff: Programmable – protects battery from over-discharge
BEC Specifications
- BEC Type: Internal – provides stable power delivery to receiver and servos
- BEC Voltage: Selectable 6V or 7.4V – supports a range of servo configurations
- BEC Continuous Current: 6A – suitable for high-demand crawler electronics
Construction and Mounting
- Case Material: Rugged plastic – impact-resistant for off-road durability
- Installation: Ready to install – no soldering required
What’s in the Box
- 1 × Spektrum Firma Smart 80 Sensored/Sensorless Brushless ESC: Outrunner
- 1 × Product Manual
What You Require / What You Will Need
- 1 × Compatible Spektrum Transmitter
- 1 × Compatible Spektrum Surface Receiver
- 1 × 2S–4S LiPo Battery with IC3 Connector
