Specifications
Radio:
- 3-channel 2.4GHz FHSS with dual rate steering and throttle, charge jack on transmitter for optional NiCd batteries.
Servo:
- High output ball bearing.
- Metal gear.
- Digital.
- 18kg-cm torque.
Motor:
- 3900Kv brushless.
- 4 pole.
- Outer Diameter ø36mm.
- Shaft ø3mm.
ESC:
- Hobbywing 60A waterproof ESC with single Deans plug battery connectors.
- Cooling fan and program card.
Chassis:
- Lightweight.
- Hard anodised CNC aluminum.
- 3mm thick.
Centre Top Brace:
- Wire pass through.
- Easy to remove with a single screw.
Drive:
- Central: Single ø4mm Hardened steel centre driveshaft.
- Optional Aluminium driveshaft H0P1-0072.
- Front: CVA axles, ø3.2mm Hardened steel.
- Rear: Dogbone, axles, ø3.2mm Hardened steel
Differentials:
- Center diff is directly connected to rear diff.
- Front, Rear and Center Differential, Metal Bevel gear, Anti-leakage Differential housing.
- Pinion Gear: 10T (MOD 1)/ Ring Gear: 39T (MOD 1).
- Center Spur Gear: 40T (MOD 1).
- Front differential filled with 5K silicone oil.
- Center differential filled with 5K silicone oil.
- Rear differential filled with 3K silicone oil.
Shocks:
- Filled with 600 silicone oil.
- Aluminium 12mm Big Body.
- 3.5mm Shaft.
- Aluminium Adjustable Ring.
- Shock Cap Protector.
Spring:
- Front: 0.86kg/cm, L=50mm, Blue.
- Rear: 0.64kg/cm, L=65mm, Blue.
- Optional Front Spring H0P1-0073: 1.00 kg/cm, L=50mm, Grey.
- Optional Rear Spring H0P1-0074: 0.73kg/cm, L=65mm, Grey.
- Shock Tower: 3mm, CNC aluminium.
- Optional carbon fiber shock tower, Front tower H0P1-0070 & Rear tower H0P1-0071.
Suspension:
- Front PBS.
- Optional aluminium steering block set H0P1-0077: Alumumium rear hub H0P1-0079.
- New strengthened composite upper arms and lower arms.( Also Fitting for older versions of the TT10).
- Optional carbon fiber arm insert H0P1-0068 and H0P1-0069.
- Front & rear anti-roll bars.
- Front and rear mg alum arm holder with pill inserts #11367, adjustable toe angles and anti-squat angles.
Steering:
- New Steering Crank set with CNC aluminium rack and hard spring.
- Ball bearing equipped with servo saver.
Battery tray:
- Motor Gear: 13T (MOD 1).
- Spur Gear: 40T (MOD 1).
Motor Mount:
- CNC aluminium laydown motor mount.
- Fitting for motors with size below 38mm.
- Spur gear cover.
Tyres:
Wheels:
- 5-Spoke wheels.
- White.
- 12mm Hex.
- Diameter 62mm.
- Width 51.2mm.
Ball Bearings:
Caster:
Camber:
