You might be familiar with the brute 1:8 scale version of the 1512-1800Kv (10AWG wire and 6.5mm bullets) that has overpowered buggies, truggies, on-road vehicles for years. Now we are offering our eBuggy version (paired with Mamba X 1:10 scale ESC), tailored with pre-soldered 4mm bullet connections and 12AWG wire!
WHY SENSORED?
Drivers in all applications demand clean starts when coming off the line. Crawler fans require high-precision low speed control and torque for climbing, racers need precision and predictability, and dragsters don't have a millisecond to spare. To achieve all of these performance demands and more, we have integrated rotor position sensor technology with our improved high power and high efficiency motor design. Through the use of our sensors, the position of the rotor is always known by the ESC. This eliminates the possibility of encountering cogging or inconsistency during startup. Users will experience PRECISE throttle control and BUTTERY SMOOTH starts plus the RAW POWER and LONGER RUN TIMES that our highly efficient motors produce.
EFFICIENCY IS KEY
The higher the efficiency of a motor the more power it can produce without overheating, which allows you to safely run higher gear ratios. The higher the efficiency of a motor, the less power it takes to produce the same output power, which allows you to run longer on a single charge. The higher the efficiency of the motor, the less energy it turns into heat; keeping it cool under extreme loads. Efficiency equals performance.
RELIABILITY CAN'T BE IGNORED
Without a robust and reliable design, efficiency will only go so far. RC enthusiasts love pushing their equipment to the edge. The Castle engineers know this and spared no expense when developing a design that could hold up to the harsh conditions that the RC community will throw at it. Oversized NMB bearings and vibration dampening system ensure the longest bearing life possible. High-strength, high-temperature grade neodymium sintered magnets combined with a high-strength Kevlar wrap ensures the integrity of the rotor is not compromised during harsh running conditions. Our proprietary winding techniques allow us to produce a stator assembly that is the lowest possible resistance, resulting in a cooler running motor. A cooler motor has a longer lifetime. Construction of our motor required careful component selection; each verified through internal testing to ensure the highest efficiency possible. In the end, the result is a motor with unmatched quality, performance, and reliability. We wouldn't put our name on anything less.
FEATURES
- Our IMPROVED 4-POLE 12-SLOT design boasts exceptional EFFICIENCY and produces LESS HEAT.
- QUIETSENSET technology shields the sensors from magnetic field noise generated from the motor coils and keeps your motor and ESC in sync at all times. Use of a Flux ShieldT in conjunction with secondary Sense Magnets delivers even HIGHER PRECISION and MORE EFFICIENT startups.
- Our OPTIMIZED design eliminates the need for mechanical timing adjustments. Our sensor alignment method delivers uniform timing and torque in both directions, automatically.
- REBUILDABLE design allows users to replace front end bell/bearing assembly or rotor/shaft assembly.
- ROAR standard sensor port and labeled connections.
- Updated modern and sleek design; looks as cool as it performs.
Immense care is taken by our US design team during every step of the development process. While using the highest quality components is important, design is equally important. Our experienced, in-house engineering team, located in Olathe, Kansas, has spent countless hours simulating and developing the most efficient design. Development includes magnetic simulations, custom winding techniques, and rigorous, real-world testing of the final product.
You will reap the benefits of longer run times on one battery and a cooler running motor that can be pushed harder.
INTEGRATED SOPHISTICATION
Castle engineers always add a little something extra in their designs that takes your performance to the next level. We have not skimped here. Many customers have utilized our industry leading software functionality that Castle Link* offers. When paired with a Castle Creations sensor supported ESC, like the MAMBA X or MAMBA MONSTER X, you can unlock advanced tuning capabilities that Castle Link provides specifically for sensored motors.
SMARTSENSET uses the motors sensors to start the motor to provide smooth starts, excellent torque, and low-speed drivability. Once the motor is turning, it seamlessly transitions to Castle's ULTRA- EFFICIENT sensorless mode. When running, a motor must transition between different load points and a different timing advance is required for optimal efficiency at all load points. Using mechanical timing adjustments alone, you can only target one driving condition, such as higher start power or higher top end speed. This sacrifices performance and efficiency during the other driving phases. Electronic timing in SMARTSENSET will advance timing automatically for peak performance during all driving conditions. This allows users to combine the best of both worlds in an unrivaled HYBRID between smooth sensored startups and high-efficiency sensorless drive.
With a Castle sensored ESC and sensored motor you will have the ULTIMATE POWER PLANT for your vehicle. Users will experience PRECISE throttle control, BUTTERY SMOOTH starts, PEAK PERFORMANCE and EFFICIENCY throughout the full throttle range. You will feel the POWER and LONGER RUN TIMES that a WORLD-CLASS motor produces.
It's not magic. it's SMARTSENSET
SPECIFICATION
- Input Voltage Range: 3s-4s LiPo
- Kv: 1800
- Max. RPM: 60,000
- Size: Length: 67.7mm / Diameter: 40mm (41.4mm with fins)
- Weight (w/wires): 385g (13.6oz) ; 336g without wires
- Shaft Size:Length: 20mm
- Diameter: 5mm
- Mounting Hole Specifications: M3 and M4 at 25mm
- Cooling Fan: Optional, coming soon!
- Connectors: 4mm male Castle Bullet Connectors, includes 210mm length sensor wire.
- Items Needed for Operation: Compatible Electronic Speed Control
- Application Guidelines: Ideal for 1:8 scale buggies weighing up to 9 lbs.
- Recommended ESC(s): Mamba X
- Max. Recommended Vehicle Weight: 9 lbs
TECH NOTE
Running modes: SMARTSENSE, Sensored, Sensorless with Castle sensored capable ESCs.
Water Resistant Design: The sensor board is coated with silicone conformal coating to protect the sensors from moisture. The sensor connections are not water resistant; water can cause signal loss which could result in loss of sensored capabilities. Castle recommended applying dielectric grease to the outside of the sensor wire connections after installation of the wire. Routine maintenance is recommended after running in wet conditions. Please refer to this document for running and maintaining motors in wet environments
Product Description of Castle M-CC060-0086-00 1512-1800kV sensored brushless motor
The Castle M-CC060-0086-00 1512-1800kV sensored brushless motor for 1/8 scale buggies is a purpose-built power unit engineered to meet the demands of high-performance eBuggy platforms. Designed for vehicles up to 9 lbs and optimized for 3S–4S LiPo configurations, this motor delivers a refined balance of torque, efficiency, and control. Castle Creations has tailored this version with pre-soldered 4mm bullet connectors and 12AWG wire, making installation seamless and current delivery reliable. The motor’s internal architecture features a 4-pole, 12-slot design that minimizes heat generation while maximizing magnetic efficiency. With integrated SmartSense™ and QuietSense™ technologies, the Castle M-CC060-0086-00 4-pole motor with SmartSense and QuietSense technology ensures buttery smooth startups and consistent timing across all load conditions.
Key features of the Castle M-CC060-0086-00 1512-1800kV motor
- Hybrid timing system - combines sensored startup with sensorless drive for optimal performance
- Kevlar-reinforced rotor - maintains structural integrity under high RPM stress
- Oversized bearings - reduce vibration and extend operational lifespan
- Low-resistance stator - improves thermal efficiency and runtime
- Dual-mode operation - supports SmartSense, sensored, and sensorless configurations
- Water-resistant sensor board - coated for moisture protection during wet runs
- Rebuildable design - allows replacement of rotor, shaft, and bearing assemblies
How does SmartSense™ deliver hybrid startup control?
SmartSense™ technology in the Castle M-CC060-0086-00 sensored inrunner motor with 5mm shaft and 4mm bullet connectors enables a hybrid timing system that transitions seamlessly between sensored and sensorless modes. At startup, the motor uses rotor position sensors to deliver smooth, cog-free launches with precise torque delivery. Once in motion, SmartSense™ automatically adjusts timing electronically to match changing load conditions, eliminating the limitations of mechanical timing adjustments. This dynamic timing control ensures peak efficiency and responsiveness whether accelerating from a standstill or navigating technical terrain.
What makes the Kevlar-wrapped rotor essential for durability?
The rotor in the Castle M-CC060-0086-00 with Kevlar-wrapped rotor and oversized NMB bearings is reinforced with high-strength Kevlar to withstand the centrifugal forces generated during high-RPM operation. This wrap prevents deformation and maintains rotor integrity under extreme throttle loads, making the motor ideal for competitive eBuggy racing. Paired with oversized NMB bearings and a vibration dampening system, the Kevlar wrap contributes to long-term reliability and smoother operation across varied terrain and driving styles.
How does QuietSense™ improve ESC-motor synchronization?
QuietSense™ technology in the Castle M-CC060-0086-00 4-pole motor with SmartSense and QuietSense technology shields the motor’s sensors from magnetic field noise generated by the coils. This shielding ensures uninterrupted communication between the motor and ESC, preventing desynchronization during throttle transitions. For 1/8 scale buggies operating in high-stress environments, QuietSense™ delivers consistent timing, smoother acceleration, and more predictable handling—especially during low-speed maneuvers and rapid directional changes.
Why is the stator design critical for thermal efficiency?
The Castle 1800kV motor with low-resistance stator and high-purity copper windings utilizes proprietary winding techniques to reduce electrical resistance across the stator assembly. This low-resistance configuration minimizes heat buildup, allowing the motor to operate cooler and more efficiently. As a result, users benefit from longer runtimes on a single charge and improved power delivery under sustained loads. The stator’s thermal efficiency is especially valuable in 1/8 scale buggies where extended sessions and aggressive driving demand consistent performance without overheating.
Is the Castle 1512 motor compatible with race-legal ESCs?
Yes. The Castle 1512 motor with ROAR sensor port and vibration dampening system includes a ROAR-compliant sensor port and clearly labeled connections, ensuring compatibility with sensored ESCs used in sanctioned racing environments. The integrated vibration dampening system protects internal components from mechanical stress, while the rebuildable design allows users to maintain peak performance by replacing worn assemblies. This flexibility makes the motor a reliable choice for both recreational and competitive drivers seeking long-term value and adaptability.
How does the water-resistant sensor board enhance reliability?
The sensor board in the Castle M-CC060-0086-00 sensored inrunner motor with 5mm shaft and 4mm bullet connectors is coated with silicone conformal material to protect against moisture intrusion. While the sensor wire connections themselves are not water-resistant, Castle recommends applying dielectric grease to the exterior of the connectors to prevent signal loss during wet runs. This added protection ensures that the motor maintains sensored capabilities even in damp conditions, making it suitable for off-road environments where exposure to water and mud is common.
Why is this motor the best Castle upgrade for hybrid control?
The Castle M-CC060-0086-00 1512-1800kV sensored brushless motor for 1/8 scale buggies combines advanced sensor integration, hybrid timing control, and rugged construction to deliver a premium power solution for eBuggy platforms. Its 4-pole configuration enhances torque and startup smoothness, while SmartSense™ and QuietSense™ ensure precise rotor alignment and consistent throttle response. The motor’s rebuildable design, water-resistant sensor board, and high-efficiency stator make it the best Castle upgrade for buttery smooth throttle and hybrid startup control.
For RC enthusiasts seeking a sensored motor with advanced timing logic, Kevlar reinforcement, and oversized bearings, the affordable Castle 1512-1800kV motor with 12AWG wire and rebuildable design offers exceptional value and performance. Buy Castle M-CC060-0086-00 sensored motor for 3S–4S eBuggy builds up to 9 lbs.
Technical Specifications of Castle M-CC060-0086-00 1512-1800kV sensored brushless motor
Brand, Model and Product Type
- Brand: Castle Creations
- Model: M-CC060-0086-00
- Product Type: Castle M-CC060-0086-00 1512-1800kV sensored brushless motor for 1/8 scale buggies, Castle M-CC060-0086-00 4-pole motor with SmartSense and QuietSense technology, Castle M-CC060-0086-00 sensored inrunner motor with 5mm shaft and 4mm bullet connectors, Castle M-CC060-0086-00 with Kevlar-wrapped rotor and oversized NMB bearings, Castle 1512 motor with ROAR sensor port and vibration dampening system, Castle 1800kV motor with low-resistance stator and high-purity copper windings
Dimensions
- Motor Length: 6.77 cm – compact and balanced for 1/8 scale eBuggy chassis
- Motor Diameter: 4 cm (4.14 cm with fins) – optimized for efficient heat dissipation
- Shaft Diameter: 0.5 cm – precision-machined for secure gear engagement
- Shaft Length: 2 cm – supports standard pinion mounting
- Product Weight: 385 g with wires / 336 g without wires – engineered for stability and vibration resistance
Motor Architecture and Performance
- Motor Type: Brushless – designed for high efficiency and minimal maintenance
- Motor Design: Inrunner – enclosed rotor configuration for consistent torque output
- Number of Poles: 4 – enhances startup torque and low-speed drivability
- Slot Configuration: 12-slot – improves motor efficiency and reduces heat generation
- RPM/Volt (Kv): 1800 kV – tuned for 3S–4S LiPo systems in 1/8 scale platforms
- Max RPM: 60,000 – supports aggressive acceleration and high-speed operation
- Input Voltage Range: 3S–4S LiPo – compatible with standard eBuggy power setups
- Application: Ideal for 1/8 scale buggies weighing up to 9 lbs
Materials and Build Quality
- Rotor Construction: Kevlar-wrapped – reinforced for structural integrity under high RPM stress
- Magnet Type: High-strength, high-temperature neodymium sintered magnets – resist thermal degradation
- Bearings: Oversized NMB bearings – extend bearing life and support high RPM loads
- Vibration Dampening: Integrated system – minimizes mechanical stress and improves longevity
- Stator Assembly: Low-resistance proprietary winding – supports cooler operation and longer runtime
Connectivity and Compatibility
- Connector Type: 4 mm male Castle bullet connectors – pre-soldered for secure, low-resistance power transfer
- Sensor Port: ROAR standard – ensures compatibility with sensored ESCs
- Sensor Wire: 210 mm length – included for flexible installation
- Recommended ESC: Castle Mamba X – optimized for full SmartSense functionality
Integrated Technologies
- SmartSense: Hybrid timing control – sensored startup with sensorless drive efficiency
- QuietSense: Shields sensors from magnetic field noise – maintains ESC-motor synchronization
- Flux Shield: Paired with secondary Sense Magnets – improves startup precision
- Sensor Alignment: Auto-adjusts timing and torque in both directions – no mechanical adjustment required
Environmental Protection
- Water Resistance: Sensor board coated with silicone conformal material – protects sensors from moisture
- Maintenance Tip: Apply dielectric grease to sensor wire connections after installation – prevents signal loss in wet conditions
Rebuildability and Maintenance
- Design: Rebuildable – allows replacement of rotor, shaft, and front end bell with bearings
Mounting and Installation
- Mounting Hole Specifications: M3 and M4 at 2.5 cm spacing – compatible with standard 1/8 scale buggy mounts
What’s in the Box
- (1) Castle 1512-1800kV 4-Pole Sensored Brushless Motor – model M-CC060-0086-00
