Power. Strength. Speed.
There is no other monster truck like E-Revo. It embodies the highest level of creativity in design and engineering that unleashed a stunning array of new technology, new innovation, and unheard of speed that reset every benchmark for racing monster truck performance. Now there is a new generation of E-Revo. This new E-Revo retains all the benefits of its original ground-breaking, award-winning design, but fortifies them with brute strength and an intense, take-no-prisoners attitude to deliver what is simply the ultimate 6s monster. Get ready for a whole new level of power, strength, and speed.
Maxx-Spec™ Driveline
Taking inspiration from its big brother X-Maxx, E-Revo’s drive system has evolved to meet today’s demands for punishing 6s performance. Jump higher. Rip harder. Release your inner beast mode. E-Revo comes out of the box ready to attack, ready for wherever your imagination takes you.
Self-Righting
E-Revo’s over-the-top power can sometimes land you upside down. Traxxas’ exclusive Self-Righting system keeps the fun going with minimal interruption. Simply press a button on the transmitter and, in most circumstances, E-Revo will be back on its wheels in just seconds.
Brutal 6s Power
Armed with a fortified drivetrain, E-Revo’s VXL-6s power system now pounds out more tire-scorching motivation than ever before, all the way to 70+ mph. Advanced design and sophisticated microprocessor control make this the most punchy and reliable high-voltage VXL power system ever. Traxxas Extreme Power is the new normal and E-Revo comes ready for any challenge.
Innovation
E-Revo breaks new ground with its stronger low-CG chassis, Maxx-Spec™ driveline upgrades, and improved driving dynamics.
Details
With just a handful of parts carrying over from the previous generation, the next generation E-Revo packs dozens of upgrades to make it the ultimate go-to vehicle for insane stunts and backyard bashing.
VXL-6s™ Waterproof Electronic Speed Control6s LiPo compatible
- Integrated cooling fan
- Real-time telemetry via Traxxas Link
- Machined heat sink
- 3-LED status indicators
- Powered accessory ports
- 10-gauge silicone wire
- Patented Traxxas High-Current Connectors
Velineon® 2200kV Brushless Motor4-pole 2200kV brushless motor
- 5mm output shaft
- Finned can for better heat dissipation
- Up to 70+ mph with Two 3s LiPo Batteries
Traxxas Stability Management® (TSM)
- Improves straight line acceleration and braking on low-traction
- surfaces
- Never dulls throttle or slows the truck
- Adjusts from off to 100% assistance from the transmitter
TQi™ 2.4GHz High Output Radio SystemTQi 2-channel transmitter
- Automatically stores and loads settings for up to 30 Traxxas Link-enabled models
- Programmable multi-function knob
- Adjustable steering and throttle percentage (dual rates)
- Adjustable steering and throttle sensitivity (exponential)
- Adjustable steering and throttle end points
- High 13ms frame rate and near-zero latency for responsive control
- 5-channel micro receiver (#6533) with fail-safe security
- Patented waterproof receiver box with easy-access plug
Drivetrain
- Maxx-Spec™ steel CVDs
- 8mm steel stub axles
- Heavy-duty telescoping center driveshafts
Transmission
- Mod-1 pinion and spur gears
- Fixed gear mesh system
- Torque-Biasing Center Drive
- Cush Drive (no slipper clutch)
- 5mm aluminum motor plate
Differentials
- Heavy-duty sealed 4-gear design
- Redesigned bulkheads with underside access
- Maxx-Spec™ ring and pinion gears
- Large 8mm output shafts
- Steel drive cups
Suspension
- Oil-filled GTR shocks with height-adjustable threaded aluminum bodies
- Inboard rocker arm suspension design for extreme articulation
- Low-CG design improves handling and protects components
- Upgraded heavy-duty axle carriers with oversized bearings
- Heavy-duty rocker arms and rod ends
Chassis
- Reinforced composite tub for greater durability
- Vented internal battery compartments with quick-release doors
- Low-CG design for improved handling
- Tough skid plates for driveline protection
ProGraphix®
- BodyClipless body mounting system
- Tough internal frame
- Adjustable rear wing
- External reinforcement for rollover protection
Wheels and Tires
- Aggressive Talon™ EXT all-terrain tires
- New tire construction resists ballooning
- Tough 3.8” black wheels
- Splined 17mm blue aluminum axle hubs
Steering
- High-throw bellcrank steering design
- Dual waterproof 2075 servos for 250 oz.-in. of torque
- Sealed Ball Bearings
- Hex hardware with Rust-Resistant Black Oxide Coating
ADDITIONAL INFO:
Come and enjoy this amazing desert truck RC model from Traxxas. This Traxxas TRX86086-4 monster Truck comes in a lovely size of 1/10 scale with quality electronics pre-assembled and ready to run. It features an electric brushless motor that will power your car to the Max beating out the rest like Arrma, Axial, or even Tamiya.
Traxxas makes the TRX86086-4 completely waterproof and built it for off-road terrain complete with a 4 wheel –drive system. E-Revo drive’s system with Traxxas’ exclusive Self-Righting system will always keep your car in complete balance and always landing on its wheel s. This system is also designed to boost your car up to 70 + mph. Traxxas stability management keeps your car in a straight line with accelerating and keeps the traction low when braking. TRX86086-4 is equipped with Talon™ EXT all-terrain tires to drive across all kinds of roads while maintaining speed and balance.
Want to test out your skills in the RC hobby with the model? Why not get this Traxxas TRX86086-4 monster Truck at your favourite RC shop right here in Walsall? We also stock up in Losi Racing, Axial, Arrma, FTX, Team Associated, Tamiya, and all the best brands for you.
Watch Video
Technical Specs
- Length: 23.05 inches (585mm)
- Width: 18.32 inches (465mm)
- Ground Clearance: 2.9 inches (73mm)
- Weight: 11.2lb (5.08kg)
- Height: 8.7 inches (221mm)
- Wheelbase: 14.94 inches (380mm)
- Front Shock Length: 3.42 inches (87mm)
- Rear Shock Length: 3.42 inches (87mm)
- Tires (pre-glued): 6.4 x 3.5 inches (162mm x 88mm)
- Wheels: 3.8 inches (97mm)
- Speed Control: Velineon® VXL-6s
- Motor (electric): 2200kV
- Transmission: Single speed
- Gear Pitch: 1.0 Metric pitch (Mod-1)
- Final Drive Ratio: 20.49:1
- Differential Type: Sealed, 4-gear
- Center Differential Type: Sealed, 4-gear (20M weight oil)
- Chassis Structure / Material: Composite tub
- Brake Type: Electronic
- Drive System: Shaft driven 4WD
- Steering: Bellcrank
- Radio System: TQi™ 2-channel transmitter with 6533 TSM receiver
- Servo: Dual 2075
- Top Speed (optional gearing): 70+ mph
- Skill Level: 3
- Battery Compartment: 156mm x 50mm x 29mm
- Gear Pitch:1.0 Metric pitch (Mod-1)
- Final Drive Ratio: 20.49:1
- Differential Type: Sealed, 4-gear
- Center Differential Type: Sealed, 4-gear (20M weight oil)
- Chassis Structure / Material: Composite tub
- Brake Type: Electronic
- Drive System: Shaft driven 4WD
- Steering: Bellcrank
- Radio System: TQi™ 2-channel transmitter with 6533 TSM receiver
- Servo: Dual 2075
- Top Speed (optional gearing): 70+ mph
- Skill Level: 3
- Battery Compartment: 156mm x 50mm x 29mm
